Product Summary
The ADV7123KSTZ140 is a triple high speed, ditital-to-analog converter on a single monolithic chip. It consists of three high speed, 10-bit, video DACs with complementary outputs, a standard TTL input interface, and a high impedance, analog output current source.
Parametrics
Absolute maximum ratings: (1)VAA to GND: 7 V; (2)Voltage on Any Digital Pin: GND - 0.5 V to VAA + 0.5 V; (3)Ambient Operating Temperature (TA): -40℃ to +85℃; (4)Storage Temperature (TS): -65℃ to +150℃; (5)Junction Temperature (TJ): 150℃; (6)Lead Temperature (Soldering, 10 sec): 300℃; (7)Vapor Phase Soldering (1 Minute): 220℃; (8)IOUT to GND1: 0 V to VAA.
Features
Features: (1)330 MSPS throughput rate ; (2)Triple 10-bit digital-to-analog converters (DACs); (3)Complementary outputs; (4)DAC output current range: 2.0 mA to 26.5 mA; (5)TTL-compatible inputs; (6)Internal reference (1.235 V); (7)Single-supply 5 V/3.3 V operation; (8)48-lead LQFP package; (9)Low power dissipation; (10)Low power standby mode.
Diagrams
<IMG border=0 src="http://www.seekic.com/uploadfile/ic-mfg/2012103025030337.jpg">
Image | Part No | Mfg | Description | Pricing (USD) |
Quantity | |||||||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
ADV7123KSTZ140 |
IC DAC VIDEO TRPL HI SPD 48-LQFP |
Data Sheet |
|
|
||||||||||||||||||
