Product Summary
The AT88SC0204CA-SU member of the CryptoMemory family is a high-performance secure memory providing 2 Kbit of user memory with advanced security and cryptographic features built in. The user memory is divided into four 64-byte zones, each of which may be individually set with different security access rights or effectively combined together to provide space for 1 to 4 data files. The AT88SC0204CA-SU features an enhanced command set that allows direct communication with microcontroller hardware 2-Wire interface thereby allowing for faster firmware development with reduced code space requirements.
Parametrics
Absolute maximum ratings: (1)Operating Temperature: -40℃ to +85℃; (2)Storage Temperature: -65℃ to +150℃; (3)Voltage on Any Pin with Respect to Ground: -0.7 to Vcc +0.7V; (4)Maximum Operating Voltage: 6.0V; (5)DC Output Current: 5.0 mA.
Features
Features: (1)One of a Family of Devices with User Memories from 1-Kbit to 8-Kbits; (2)2-Kbit (256-byte) EEPROM User Memory; (3)2-Kbit Configuration Zone: 37-byte OTP Area for User-defined Codes; 160-byte Area for User-defined Keys and Passwords; (4)High Security Features: 64-bit Mutual Authentication Protocol (Under License of ELVA); Cryptographic Message Authentication Codes (MAC); Stream Encryption; Four Key Sets for Authentication and Encryption; Eight Sets of Two 24-bit Passwords; Anti-Tearing Function; Voltage and Frequency Monitors.
Diagrams
<IMG border=0 src="http://www.seekic.com/uploadfile/ic-mfg/2012103025154172.jpg">
Image | Part No | Mfg | Description | Pricing (USD) |
Quantity | |||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
AT88SC0204CA-SU |
Atmel |
EEPROM Ind Temp Green |
Data Sheet |
|
|
|||||||||||||
