Product Summary
The AD8608ARZ-REEL7 is a single, dual, and quad rail-to-rail input and output, single-supply amplifier. It is suitable for Photodiode amplification, Battery-powered instrumentation, Multipole filters, Sensors, Barcode scanners and Audio.
Parametrics
Absolute maximum ratings: (1)Supply Voltage: 6 V; (2)Input Voltage: GND to VS; (3)Differential Input Voltage: 6 V; (4)Output Short-Circuit Duration to GND: Observe Derating Curves; (5)Storage Temperature Range: -65℃ to +150℃; (6)Operating Temperature Range: -40℃ to +125℃; (7)Junction Temperature Range: -65℃ to +150℃; (8)Lead Temperature (Soldering, 60 sec): 300℃.
Features
Features: (1)Low offset voltage: 65 μV maximum; (2)Low input bias currents: 1 pA maximum; (3)Wide bandwidth: 10 MHZ; (4)High open-loop gain: 1000 V/mV; (5)Unity gain stable; (6)Single-supply operation: 2.7 V to 5.5 V.
Diagrams
<IMG border=0 src="http://www.seekic.com/uploadfile/ic-mfg/2012103025844306.jpg">
Image | Part No | Mfg | Description | Pricing (USD) |
Quantity | |||||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
AD8608ARZ-REEL7 |
IC OPAMP GP R-R CMOS QUAD 14SOIC |
Data Sheet |
|
|
||||||||||||||||
