Product Summary

The ADXL345BCCZ-RL7 is a digital accelerometer. It is suitable for handsets, medical instrumentation, gaming and pointing devices, industrial instrumentation, personal navigation devices and hard disk drive (HDD) protection.

Parametrics

Absolute maximum ratings: (1)VS: -0.3 V to +3.9 V; (2)VDD I/O: -0.3 V to +3.9 V; (3)Digital Pins: -0.3 V to VDD I/O + 0.3 V or 3.9 V, whichever is less; (4)All Other Pins: -0.3 V to +3.9 V; (5)Output Short-Circuit Duration (Any Pin to Ground): Indefinite.

Features

Features: (1)Ultralow power: as low as 23 μA in measurement mode and 0.1 μA in standby mode at VS = 2.5 V (typical); (2)Power consumption scales automatically with bandwidth; (3)Patent pending, embedded memory management system with FIFO technology minimizes host processor load; (4)Single tap/double tap detection; (5)Activity/inactivity monitoring; (6)Free-fall detection; (7)Supply voltage range: 2.0 V to 3.6 V; (8)I/O voltage range: 1.7 V to VS; (9)SPI (3- and 4-wire) and I2C digital interfaces; (10)Flexible interrupt modes mappable to either interrupt pin; (11)Measurement ranges selectable via serial command; (12)Bandwidth selectable via serial command; (13)10,000 g shock survival; (14)Pb free/RoHS compliant; (15)Small and thin: 3 mm × 5 mm × 1 mm LGA package.

Diagrams

<IMG border=0 src="http://www.seekic.com/uploadfile/ic-mfg/2012103025147127.jpg">

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
ADXL345BCCZ-RL7
ADXL345BCCZ-RL7


IC ACCEL SPI/I2C 3AX 14LGA

Data Sheet

0-1: $4.29
1-10: $3.86
10-25: $3.51
25-100: $3.18
100-250: $2.91
250-500: $2.66
