Product Summary

informationThese hex buffers/drivers feature high-voltageopen-collector outputs to interface with high-levelcircuits or for driving high-current loads. They arealso characterized for use as buffers for driving TTL inputs. The ’LS07 devices have a rated output voltage of30 V, and the SN74LS17 has a rated output voltage of 15 V. The maximum sink current is 30 mA for theSN54LS07 and 40 mA for the SN74LS07 and SN74LS17.These circuits are compatible with most TTL families. Inputs are diode-clamped to minimize transmission-lineeffects, which simplifies design. Typical power dissipation is 140 mW, and average propagation delay time is12 ns

Features

Convert TTL Voltage Levels to MOS LevelsD High Sink-Current CapabilityD Input Clamping Diodes Simplify SystemDesignD Open-Collector Driver for Indicator Lampsand Relays

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
SN74LS07N
SN74LS07N

Texas Instruments

Buffers & Line Drivers Hex W/ OC HV Out

Data Sheet

0-1: $0.53
1-25: $0.48
25-100: $0.42
100-250: $0.37
SN74LS07NE4
SN74LS07NE4

Texas Instruments

Buffers & Line Drivers Hex Buffer/Driver

Data Sheet

0-1: $0.53
1-25: $0.43
25-100: $0.39
100-250: $0.35
SN74LS07NSR
SN74LS07NSR

Texas Instruments

Buffers & Line Drivers Hex Buffer/Driver

Data Sheet

0-1: $0.53
1-25: $0.48
25-100: $0.42
100-250: $0.37
SN74LS07NSRE4
SN74LS07NSRE4

Texas Instruments

Buffers & Line Drivers Hex Buffer/Driver

Data Sheet

0-1400: $0.25
1400-2000: $0.23
2000-5000: $0.22
5000-10000: $0.22
SN74LS07NSRG4
SN74LS07NSRG4

Texas Instruments

Buffers & Line Drivers Hex Buffer/Driver

Data Sheet

0-1400: $0.25
1400-2000: $0.23
2000-5000: $0.22
5000-10000: $0.22
