Product Summary

informationThesehexinverterbuffers/driversfeaturehigh-voltage open-collector outputs to interfacewith high-level circuits (such as MOS), or fordrivinghigh-currentloads,andalsoarecharacterized for use as inverter buffers for drivingTTL inputs. The ’LS06 devices have a rated outputvoltage of 30 V, and the SN74LS16 has a ratedoutput voltage of 15 V. The maximum sink currentfor the SN54LS06 is 30 mA, and for theSN74LS06 and SN74LS16 it is 40 mA.These devices are compatible with most TTLfamilies. Inputs are diode-clamped to minimizetransmission effects, which simplifies design.Typical power dissipation is 175 mW, and averagepropagation delay time is 8 ns
