Product Summary

The TLE4266GS V10 is a low-drop voltage regulator for 5 V or 10 V supply in a PG-SOT223-4 SMD package. The IC regulates an input voltage VI in the range of 5.5 V/10.5 V < VI < 45 V to VQ,nom = 5 V/10 V. The maximum output current of TLE4266GS V10 is more than 120 mA. The IC can be switched off via the inhibit input, which causes the current consumption to drop below 10 μA. The TLE4266GS V10 is shortcircuit-proof and incorporates a temperature protection which turns off the IC at overtemperature.

Parametrics

TLE4266GS V10 absolute maximum ratings: (1)Voltage Current: -42 to 45 V; (2)Voltage Output: -42 to 45 V; (3)Voltage Current: -1 to 32 V; (4)Current: 50 mA min; (5)Junction temperature: 150 ℃; (6)Storage temperature: -50 to 150 ℃.

Features

TLE4266GS V10 features: (1)Output voltage 5 V or 10 V; (2)Output voltage tolerance ≤ ±2%; (3)120 mA current capability; (4)Very low current consumption; (5)Low-drop voltage; (6)Overtemperature protection; (7)Reverse polarity proof; (8)Wide temperature range; (9)Suitable for use in automotive electronics; (10)Inhibit; (11)Green Product (RoHS compliant); (12)AEC Qualified.

Diagrams

<IMG border=0 src="http://www.seekic.com/uploadfile/ic-mfg/2012103025213127.jpg">

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
TLE4266GS V10
TLE4266GS V10

Infineon Technologies

Low Dropout (LDO) Regulators LOW DROPOUT REGULATOR

Data Sheet

0-2870: $0.40
2870-4000: $0.40
4000-8000: $0.38
8000-12000: $0.36
