Product Summary

The ADUM5402ARWZ-RL is a quad-channel isolator with integrated DC-to-DC converter. It is suitable for RS-232/RS-422/RS-485 transceivers, industrial field bus isolation, power supply startup bias and gate drives, isolated sensor interfaces and industrial PLCs.

Parametrics

Absolute maximum ratings: (1)Storage Temperature (TST): -55℃ to +150℃; (2)Ambient Operating Temperature (TA): -40℃ to +105℃; (3)Supply Voltages (VDD, VISO): -0.5 V to +7.0 V; (4)Input Voltage (VIA, VIB, VIC, VID, VSEL): -0.5 V to VDDI + 0.5 V; (5)Output Voltage (RCOUT, VOA, VOB, VOC, VOD): -0.5 V to VDDO + 0.5 V; (6)Average Output Current Per Data Output Pin4: -10 mA to +10 mA; (7)Common-Mode Transients5: -100 kV/μs to +100 kV/μs.

Features

Features: (1)Regulated 3.3 V or 5.0 V output; (2)Up to 500 mW output power; (3)Quad dc-to-25 Mbps (NRZ) signal isolation channels; (4)Schmitt trigger inputs; (5)16-lead SOIC package with >8.0 mm creepage; (6)High temperature operation: 105℃; (7)High common-mode transient immunity: >25 kV/μs.

Diagrams
